| PEI Model | 12x12 | 12x14 | 15x17 | 18x18 | 18x20 | 20x22 | 20x25 |
|---|---|---|---|---|---|---|---|
| Capacity (MT/Hr.) | 2-5 | 3-5 | 5-6 | 7-8 | 9-11 | 12-15 | 15-20 |
| Motor Power (KW) Cooler + Vane feeder |
1.1 + 0.55 | 1.5 + 0.55 | 1.5 + 0.55 | 2.2 + 0.75 | 2.2 + 1.2 | 3.0 + 1.5 | 3.0 + 2.0 |
- Stainless steel rotary air-lock feeder for uniform feeding / distribution of pellets in cooling chamber.
- Air versus Pellets counter flow enables the pellet to be cooled gradually thus minimizing the risk of “cooling shock”.
- Sturdy grid discharge system ensures minimize of fine occurrence and high hygienic standards.
- Automatic gate discharge closure in the event of power failure to avoid spillage of pellet feed.
- Adjustable Hi-Low level proximity sensor for the required fill level of pellets in the cooling chamber.
- Easy access doors for maintenance and cleaning of cooling chamber.
- Full stainless steel compact design – less floor space.
