| PEICR Model | 20x60 | 20x80 | 20x100 | 20x120 | 20x150 | 25x150 |
|---|---|---|---|---|---|---|
| Roller Size | 200 x 600 | 200 x 800 | 200 x 1000 | 200 x 1200 | 200 x 1500 | 200 x 1500 |
| Capacity (MT/Hr.) | 2-3 | 4-5 | 6-8 | 8-10 | 10-12 | 12-15 |
| Motor Power (KW) | 2.2 | 3.75 | 5.5 | 7.5 | 9.5 | 15 |
- The crumbler rolls are grooved with different flutes ( TPI ) to suit the product sizing.
- Differential rotational speed of rolls for perfect crumbling.
- Rotary feeder for even distribution of pellets along the length of rolls.
- sturdy and robust drive for slip free crumbling.
- Large roll cleaning / inspection door for ease of maintenance.
- Pressure-cast chilled roll with desired TPI.
- precise spring loaded geared roll-gap adjustment.
- Low noise and negligible maintenance.
- Feed diverter flap for bypassing pellets.
Multiple crumblers placed in parallel or in series for higher capacities or for finer crumbling.
